HPE DL380 Gen10 Plus Rack Servers

Processor Qty 1 or 2 Processor Cores4-Core Min to 40-Core Max Processor ModelsProcessor GHz1.9GHz to 3.6GHzProcessor ModelsIntel Xeon 3rd Generation Scalable

Maximum Capacity8TB (32x 256GB)RAM Speeds3200 MT/sTotal DIMM Slots32

Drive Bay Capacity24 Small Form Factor 2.5" / 12 Large Form Factor 3.5" / 2 M.2 NVMeDrive TypesSAS Spinning Disk, SATA SSD, SAS SSD, NVMe SSDMax Capacity (2.5")SAS Spinning Disk (397.8TB), SAS SSD (583.3TB), SATA SSD (291.84TB), NVMe SSD (385.92TB)Max Capacity (3.5")SAS/SATA Spinning Disk (360TB), SAS SSD (11.5TB), SATA SSD (11.5TB)

Slot Qty1OCP Card Types1Gbit, 10Gbit, 25Gbit, 40Gbit, 50Gbit, 100Gbit Ethernet Adapters

Full Height Slot Qty8x PCIe 4.0

AROC InternalHardware RAID 2GB Cache RAID0/1/5/6/10/50/60OCP InternalHardware RAID 4GB Cache RAID0/1/5/6/10/50/60PCIe InternalHardware RAID 2GB-4GB Cache RAID0/1/5/6/10/50/60PCIe ExternalHardware RAID 4GB RAID0/1/5Software RAIDVROC No Cache RAID0/1/5/10Supported ProtocolsSATA 6Gb/s, SAS 12Gb/s & 24Gb/s, NVMe

Double-Width/Full-Length)2Single-Width/Full-Length8Single-Width/Three-Quarter-Length0

Power Suppy Qty1 or 2Power Supply Wattage800W AC, 800W VDC, 1000W AC, 1600W AC, 1600W VDC, 1800-2200W AC
